Example 25: Cool ICE dynamic graph option 3

Click here for information about Cool ICE

This example shows how to use the Cool ICE Graphics Interface Routine entry point 003 to create a graph and display it in an html page.
The graph shows inventory level by product.

Graph produced on 21 NOV 24 at 12:16:03

Error returned from graphics server:

Things you may want to note:

The Cool ICE Graph Interface Routine entry point 003 allows you to produce highly customizable graphs by specifying all available parameters.
The interface provides 4 different options for specifying the source of the graph parameters.
This example is using option 3 for specifying the parameters.
Option 3 specifies that the graph parameters are contained in a state management report.
The img tag in this example is not using the viewer.asp to display the image, which means the image file will stay on the server until it is removed by the ICECleanUp garbage collection.
This example is using a fixed template for graph parameters and is appending graph parameters that are specific to this graph to the end of the template. This service is adding the ExplodeSliceRow parameter to explode slices of the pie where QTY is greater than 900 units.
